How to configure DNS host mapping on your modem

DNS host mapping creates a static hostname for the specified IP address in the DSL router. Both WAN and LAN IP addresses are supported.

Note:  Your modem settings may appear slightly different from the images below, but the steps will be the same.

5. Select DNS Host Mapping in the left sidebar. This menu option may appear in the LAN Settings section or in the IP Addressing section, depending on your model.

DNS Host Mapping Step 5

6. Follow the steps to edit the DNS Host Mapping settings.


  • Step 1:  Enter the desired DNS host name.

  • Step 2:  Enter the IP address. You can also click to remove items from the DNS Host Mapping List at the bottom.

  • Step 3:  When you're finished adding or removing items, click "Apply" to save your changes.
DNS Host Mapping Step 6
